Max. workpiece Ø 350 mm

Max. modulus f. hobbing cutters 8 mm

Max. addendum circle Ø 163 mm

L max. 230 mm (depending on cutter arbour Ø)

Cutter cutter Ø 22, 27, 32, 40 mm

Mounting taper MK5

Radial carriage travel 225 mm

Tangential carriage travel 170 mm

Axial carriage travel 250 mm

Max. cutter head pivoting angle +30°...-40°

#workpiece spindle outside Ø 350 mm

Workpiece spindle bore 150 mm

Counterholder travel 550 mm

Counterholder bore 150 mm

Speed - tool 120-400 rpm

Speed - tool spindle 1-40 rpm

Rapid speed on X axis 5,000 mm/min.

Rapid speed on Y axis 750 mm/min.

Rapid speed on Z axis 1,000 mm/min.

Autom. workpiece feeding unit

Cooling lubricant system

Oil mist extraction and filtering system
