Gear Related Machines

Technical data:

• Max. centre width: 600 mm
• Centre height: 155 mm
• Maximum clamping length for arbors: 700 mm
• Max. table travel: 550 mm
• Maximum grinding depth: 90 mm
• Table speed infinitely variable: 0-16 m/min
• Axial adjustment of the grinding spindle: 220 mm
• Vertical adjustment of the grinding slide: 200 mm
• Speed of the grinding spindle in standard version: 2200 rpm
• Largest number of flutes: 44
• Swivelling range of the grinding slide on both sides: 45 degrees
• Swivelling range of the grinding spindle from the horizontal to the top: 15 degrees
• Largest grinding wheel diameter: 300 mm
• Smallest grinding wheel diameter: 150 mm
• Largest workpiece diameter: 300 mm
• Taper of the main spindle: Morse 4
